Example in this product is shown below.
This product supports only Basic Device ID.
Response format: Unit ID = 251 (Communication module)
Byte
Meaning
Example value
0
Function Code = 2Bh
0x2B
1
Type of MEI
0x0E
2
Read Device ID code
0x01: Basic
3
Conformity Level
0x02
4
More Follows
0: No more Object
5
Next Object Id
0
6 Number Of Objects 3 for Basic.
6 for Regular or Extended
7
Obj 0 Id

Vendor Name
0
8
Obj 0 length
7
9-15
Obj 0 value
“TOSHIBA”
16
Obj 1 Id

ProductCode
1
17
Obj 1 length
7
18-24
Obj 1 value
“PNE001Z”
25
Obj 2 Id  Version
2
26
Obj 2 length
4
27-30
Obj 2 value
“0201”
Exception response format:
Byte
Meaning
0
Function Code = 0xAB
1
Exception Code
01: Illegal Function
02: Illegal Data Address
03: Illegal Data Value
