Toshiba TOSVERT VF-AS3 Manual

E6582051
- 39 -
6.5.3.
fa23
(Communication command 2) (VF-S15)
bit
Function
0
1
Note
0
(Reserved)
-
-
-
1
Electric power quantity
reset
OFF Reset
Electric power quantity (
fe76
,
fe77
) reset
2
(Reserved)
-
-
-
3
(Reserved)
-
-
-
4
(Reserved)
-
-
-
5
(Reserved)
-
-
-
6
(Reserved)
-
-
-
7
Maximum deceleration
forced stop
Normal Enabled -
8
Acceleration/decele-
ration selection 1
00: Acceleration/deceleration 1
01: Acceleration/deceleration 2
10: Acceleration/deceleration 3
Select acceleration/deceleration
1-4 by combination of two bits.
AD1:
acc
,
dec
AD2:
f500
,
f501
AD3:
f510
,
f511
9
Acceleration/decele-
ration selection 2
10
(Reserved)
-
-
-
11
(Reserved)
-
-
-
12 OC stall level switch OC stall 1 OC stall 2
OC stall 1:
f601
OC stall 2:
f185
13
(Reserved)
-
-
-
14
(Reserved)
-
-
-
15
(Reserved)
-
-
-
Note: Set 0 to reserved bit.

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
