6.5.13. fd01 (Inverter operating status 1 (real time)) (VF-AS3)
bit
Function
0
1
Note
0
Failure FL
No output
Under in progress
-
1 Failure Not tripped Tripped
Trip status includes
rtry
and
the trip retention status are also
regarded as tripped statuses.
2
Alarm
No alarm
Alarm issued
-
3
Under voltage (
moff
)
Normal
Under voltage
-
4 V/f switching status V/f 1 V/f 2
V/f 1:
pt
= setting value,
vl
,
vlv
,
vb
,
thra
V/f 2:
pt
=
0
,
f170
,
f171
,
f172
,
f182
5 PID control off
PID control
permitted
PID control
prohibits
-
6 Acc/Dec switching status
AD mode 1 AD mode 2
AD mode 1:
acc
,
dec
AD mode 2:
f500
,
f501
7 DC braking OFF
Forced DC
braking
-
8
Jog run
OFF
Jog run
-
9
Forward / reverse run
Forward run
Reverse run
-
10
Run/stop
Stop
Run
-
11
Coast stop (ST = OFF)
ST=ON
ST=OFF
-
12 Emergency stop
No emergency
stop status
Emergency
stop status
-
13 Standby ST=ON Start-up process Standby
Standby: Initialization
completed, not failure stop
status, not alarm stop status
(
moff
,
ll
forced stop),
ST=ON, and RUN=ON
14 Standby Start-up process Standby
Standby: Initialization completed,
not failure stop status and not
alarm stop status (
moff
,
ll
forced stop)
15
HAND/AUTO
(LOC/REM)
AUTO
(REM)
HAND
(LOC)
Enabled with
f750
=”2”
HAND: Panel operation is enabled
AUTO:
Operation method selected
cmod
and
fmod
are enabled.
Enabled with
f732
=”0”
LOC: Panel operation is enabled
REM: Operation method selected
cmod
and
fmod
are enabled.
