6.8.1.3. Example3. Reading the status monitor parameter (
fe02
(The operation frequency))
AK = 6 (Request parameter value (array))
SPM = 0
PNU = 1
IND = 0xFE02 (
fe02
communication number)
PKE
0
1
1
0
0
0
0
0
0
0
0
0
0
0
0
1
6
0
0
1
Requirement
PKW PZD
PKE IND PWE
60
01
FE
02
00
00
00
00
･･･
･･･
Response (Value: 0x03E8 (= 1000 -> 10.00Hz))
40
01
FE
02
00
00
03
E8
･･･
･･･
* The status monitor parameter can not be changed.
6.8.1.4. Example4. Changing the basic parameter (
acc
(acceleration time))
AK = 7 (Change parameter value (array))
SPM = 0
PNU = 1
IND = 0x0009 (
acc
communication number)
PKE
0
1
1
1
0
0
0
0
0
0
0
0
0
0
0
1
7
0
0
1
Requirement (
acc
= 7.0 sec. -> 70 (= 0x0046) *)
PKW PZD
PKE IND PWE
70
01
00
09
00
00
00
46
･･･
･･･
Response
40
01
00
09
00
00
00
46
･･･
･･･
* When the “Acceleration time” is set to 7.0 sec., set the following value.
(The unit of the “Acceleration time” is according to the parameter
f519
.)
7.0 / 0.1 = 70 = 0x0046 (hexadecimal number)
Notes
When the control power is shut off by the instantaneous power failure, communication will be
unavailable for a while.
