Toshiba TOSVERT VF-AS3 Function Manual

E6582051
- 10 -

The behavior of BF LED
Module Status
Color and behavior Meaning
OFF The device is powered off
Green/Red blinking Power up testing
Green flashing In combination with other LEDs : DCP manual identification phase /
DCP flash mode
Green ON The device is ready and operational
Red Single flash No connection to the PROFINET Controller (PLC)
Red flickering The option has detected a communication error (
err8
)
Red ON The option has detected a option module error (
e-23
)

The behavior of SF LED
Network Status
Color and behavior Meaning
OFF The option does not have IP address or powered off
Green/Red blinking Power up testing
Green flickering In combination with other LEDs: DCP manual identification phase /
DCP flash mode
Green flashing 3 times All ports are unplugged, but the card has an IP address
Green flashing 4 times Error: duplicate IP address
Green flashing 5 times The card is performing a DHCP sequence
Green ON At least a port is connected and has a valid IP address.
Red ON General error on the module
If the communication card operates as a Modbus TCP server only, LNK LEDs work as follows.

The behavior of LNK LED for Modbus TCP
Link Activity
Color and behavior Meaning
OFF No link
Green Blink Network Activity at 100 Mbps
Green ON Link established at 100 Mbps
Yellow Blink Network Activity at 10 Mbps
Yellow ON Link established at 10 Mbps

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
