E6582051
- 49 -
6.5.22.
fd06
(Input TB Status) (VF-S15/MB1)
bit TB Name Function (Parameter) 0 1
0 F Input terminal function selection 1 (
f111
)
OFF ON
1 R Input terminal function selection 2 (
f112
)
2 RES Input terminal function selection 3 (
f113
)
3 S1 Input terminal function selection 4 (
f114
)
4 S2 Input terminal function selection 5 (
f115
)
5 S3 Input terminal function selection 6 (
f116
)
6 VIB*1 Input terminal function selection 7 (
f117
)
7 VIA*1 Input terminal function selection 8 (
f118
)
8 to 15 (Undefined) - - -
Note: The bit described "Undefined" is unstable. Do not use the bit for the judgment.
*1: VIA/ VIB are input terminal function when
f109
is logic input.
*The input terminal function is selected by each parameter.
6.5.23. fd06 (Input TB Status) (VF-AS3)
bit TB Name Function (Parameter) 0 1
0 F
f111:
Input terminal function selection 1
OFF ON
1 R
f112:
Input terminal function selection 2
2 RES
f113:
Input terminal function selection 3
3 S1
f114:
Input terminal function selection 4
4 S2
f115:
Input terminal function selection 5
5 S3
f116:
Input terminal function selection 6
6 S4*1
f117:
Input terminal function selection 7
7 S5*2
f118:
Input terminal function selection 8
8 DI11*3
f119:
Input terminal function selection 9
9 DI12*3
f120:
Input terminal function selection 10
10 DI13*3
f121:
Input terminal function selection 11
11 DI14*3
f122:
Input terminal function selection 12
12 DI15*3
f123:
Input terminal function selection 13
13 DI16*3
f124:
Input terminal function selection 14
14 to 15 (Undefined) - - -
Note: The bit described "Undefined" is unstable. Do not use the bit for the judgment.
*1: Only when the contact input has been selected with f147 (Digital/ Pulse train/PG input),
it is an effective value.
*2: Only when the contact input has been selected with f148 (Digital/ Pulse train/PG input),
it is an effective value.
*3: DI11 – DI16 are the terminals of I/O extension.
