E6582051
- 4 -
■
Wiring
Warning
Mandatory
▼
Shut off power when installing and wiring this option.
Wait at least 15 minutes and check to make sure that the charge lamp
(VF-S15/AS3/MB1) is no longer lit.
▼
Electrical construction work must be done by a qualified expert.
Installation or connection of input power by someone who does not have that expert
knowledge may result in fire or electric shock.
■
Operations
Warning
Prohibited
▼
Do not touch switches when the hands are wet and do not try to clean the inverter with a
damp cloth.
Doing so could result in electric shock.
▼
Do not pull on any cable itself.
Doing so could result in damage or malfunction.
■
Cautions for the communication
Warning
Prohibited
▼
Do not set the value that exceeds an effective range as data.
The motor may suddenly restart or stop and that could result in injury.
Mandatory
▼ Check PROFINET state (using below status word bit) when the option unit is deactivated
by an unusual event such as an operating error, power outage, failure, etc.
- ZSW Status Word Bit 3 (Fault), Bit 7 (Warning)
(The communication error occurs when "1" as value or this value cannot be read.)
Deactivated option unit may cause an accident, if the PROFINET state is not checked.
▼ Make sure that the operation signals are STOP before clearing the inverter’s fault.
The motor may suddenly start and that may result in injuries.
■
Disposal
Caution
Mandatory
▼
For safety's sake, do not dispose of the disused inverter yourself but ask an industrial
waste disposal agent (*).
If the collection, transport and disposal of industrial waste are done by someone who is
not licensed for that job, it is a punishable violation of the law. (Laws in regard to cleaning
and processing of waste materials)
(*) Persons who specialize in the processing of waste and known as “industrial waste
product collectors and transporters” or “industrial waste disposal persons.”
To Next Page
