STE 80722
– 6 –
(Speed) : Select the speed for data communication from the following six (6)
rates.
115200 : 115200 bps * Host port only
38400 : 38400 bps
19200 : 19200 bps
9600 : 9600 bps
4800 : 4800 bps
2400 : 2400 bps
1200 : 1200 bps
(Character length) : Specify the length of characters to be transferred.
8 : 8 bits
7 : 7 bits
(Parity) : Specify the parity of characters to be transferred.
0 : Without parity
1 : Odd-number parity
2 : Even-number parity
(Stop bit length) : Specify the stop bit length of characters to be transferred.
1 : Stop bit 1
2 : Stop bit 2
Set value
Example: TS3000
= 9600 8 0 1
= 38400 8 1 1
"Speed 9,600 bps, character length 8 bits, without parity and stop bit 1" are specified
for the COM1 port.
"Speed 38,400 bps, character length 8 bits, even-number parity and stop bit 1" are
specified for the HOST port.
