COMMUNICATION MANUAL
series Robot Controller
No. Command Descriptions Details Text
40 SM Motion status Motion status information
acquisition
SM, version
41 HI Input signal read Hexadecimal-coding and
reading of Input signal
HI, signal name signal
length
42 ZC 3-axis origin position
change information
3-axis origin position
change information
request
ZC
43 EM Controller mode change EXT.SIG change request EM, 0
EXT.RS232C change
request
EM, 1
EXT.ETHER change
request
EM, 2
* The internal commands executable by the EC command are as follows:
(1) MODE
(2) OVRD
(3) BREAK
Table 5.2 List of commands (Controller → Host computer)
No. Command Descriptions Details Text
1 FL* File FL, File contents
2 OK Acknowledge OK
3 NG Non-acknowledge NG
* The following files can be sent with the FL command.
(1) RAM files
 User file (program and positional data)
 Parameter file
(2) File directories
(3) Status files
(4) Error history files
(5) System total status files
(6) Version information files
(7) Variable read data files
(8) Currently occurring alarm
