Register / Coil Tag Name Read / Write Description
COM2 failed node
reconnect control
If this bit is set communication with the failed
nodes is detected after scan time SW0019 for
port2.By default : ON
S0023 COM3 failed node
reconnect control
Read/write If this bit is set communication with the failed
nodes is detected after scan time SW0022 for
port3. By default : ON
Shows the status of the node, whether node is
present or
not.
Total 2 word Register are mapped
for 32 nodes.
Node Status Registers
for
COM1
Shows the status of the node, whether node is
present or not. Total 14 word Register are mapped
for 224 nodes.
SW80-S81 Node Status Registers
for
COM2
Read only Shows the status of the node, whether node is
present or
not.
Total 2 word Register are mapped
for 32 nodes.
SW82-S95 Node Status Registers
for
COM2
Read only Shows the status of the node, whether node is
present or not. Total 14 word Register are mapped
for 224 nodes.
Shows the status of the node, whether node is
present or not. Total 16 word Register are mapped
for 256 nodes.
