Chapter 3 Functions
6F8C1657
26
3.2.1 Common memory area of typeL
The slot numbers corresponding to DCS is 1, Windows is 3, Receiving area for inter-
controller transmission (AW) is 20, Tag Parameters are 40 and 41, Expansion
Register(EW) are 42 to 45. A part of the common memory area is shown in the following
figure. In the figure, Station Offset indicates the absolute address in the common memory
area, and Slot Offset indicates the relative address in the 2 Mbyte area for each slot.
Station Offset
(Byte)
Slot Offset
(Byte)
0x00000000
0x00000000
Lead offset of slot 0
0x00200000
0x00000000
Lead offset of slot 1 (DCS)
0x00284000
0x00084000
User area (DCS)
844 Kbyte (422 Kword)
System register(ZW) / TAG data
0x0036EC00
0x0016EC00
0x00400000
0x00000000
Lead offset of slot 2
0x00600000
0x00000000
Lead offset of slot 3 (Windows)
0x00670000
0x00070000
User area (Windows)
64 Kbyte (32 Kword)
Station Global (Windows)
0x00680000
0x00080000
0x02800000
0x00000000
Lead offset of slot 20 (FN)
0x02860000
0x00060000
User area DCS
128Kbyte (64 Kword)
Receiving area for inter-controller
transmission (AW)
0x02880000
0x00080000
0x05000000
0x00000000
User area DCS
2Mbyte (1Mword)
Lead offset of slot 40 (Expansion)
Tag Parameter (PB)
0x051FFE20
0x001FFE20
