Technical Information
Service Manual
Model TW18HQ1C8D
Product Code CB456000300_L59684
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 18000
Heating Capacity(Min~Max) Btu/h 19000
Cooling Power Input(Min~Max) W 1920
Heating Power Input(Min~Max) W 2000
Cooling Power Current A 8.5
Heating Power Current A 8.9
Rated Input W 2600
Rated Current A 11.54
Air Flow Volume(SH/H/M/L) CFM 471/403/341/282
Dehumidifying Volume Pint/h 3.80
EER (Btu/h)/W 9.37
COP (Btu/h)/W 9.50
SEER 16.00
HSPF 9.00
Application Area yd
2
27.50-40.66
Indoor Unit
Model of indoor unit TW18HQ1C8D/I
Indoor Unit Product Code CB456N00300_L59684
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 1/6×27 4/5
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/900
Fan Motor Heating Speed(SH/H/M/L) r/min 1300/1200/1100/900
Output of Fan Motor W 30
Fan Motor RLA A 0.30
Fan Motor Capacitor μF 2.5
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ5/16
Row-n Gap inch 2-1/18
Coil Length (LXDXW) inch 28 1/7×1×12
Swing Motor Model MP35CJ
Output of Swing Motor W 2.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 46/42/39/35/-
Sound Power Level(SH/H/M/L) dB (A) 56/52/49/45/-
Dimension (WXHXD) inch 38 3/16X11 13/16X8 13/16
Dimension of Carton Box (LXWXH) inch 40 7/8X15X12
Dimension of Package (LXWXH) inch 41X15X12 5/8
Net Weight Ib 29.8
Gross Weight Ib 36.4
