9
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit TW18HQ1C8D/O
Outdoor Unit Product Code CB427W02000_L59684
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model QXA-B141zF030A
Compressor Oil RB68EP
Compressor Type Rotary
Compressor Locked Rotor Amp (L.R.A) A 25.00
Compressor RLA A 12.08
Compressor Power Input W 1440
Overload Protector 1NT11L-6233 or KSD115
℃
or HPC115/95U1
Throttling Method Capillary
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/8
Rows-n Gap inch 1-1/18
Coil Length (LXDXW) inch 33 5/8×26× 6/7
Fan Motor Speed rpm 800
Output of Fan Motor W 60
Fan Motor RLA A 0.52
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 1883
Fan Type Axial-ow
Fan Diameter inch Φ20 1/2
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 550
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 240
Sound Pressure Level (H/M/L) dB (A) 59/-/-
Sound Power Level (H/M/L) dB (A) 69/-/-
Dimension (WXHXD) inch 38X27 9/16X15 5/8
Dimension of Carton Box (LXWXH) inch 40 3/8X17 7/8X29
Dimension of Package (LXWXH) inch 40 1/2X18X29 1/2
Net Weight Ib 95.9
Gross Weight Ib 105.8
Refrigerant R410A
Refrigerant Charge oz 49.4
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ1/2
Max Distance Height ft 32.8
Max Distance Length ft 82.0
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
