Technical Information
Service Manual
Model GWC24AGEXH-D3DNA1A
GWH24AGEXH-D3DNA1A
GWH24AGEXH-D3DNA4A
Product Code CB385016400
CB385016300
CB558009000
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 22000 22000
Heating Capacity Btu/h / 24000
Cooling Power Input W 1679 1679
Heating Power Input W / 1870
Cooling Power Current A 8.1 8.1
Heating Power Current A / 8.8
Rated Input W 2600 3100
Rated Cooling Current A 15.3 15.3
Rated Heating Current A / 13.5
Air Flow Volume CFM 736/589/530/471/441/412/383 736/589/530/471/441/412/383
Dehumidifying Volume Pint/h 5.07 5.072
EER (Btu/h)/W 13.1 13.1
COP (Btu/h)/W / 12.8
SEER 24 24
HSPF / 11
Application Area yd
2
32-50 32-50
Indoor
Unit
Model of indoor unit GWC24AGEXH-D3DNA1A/I
TW24HXP2A1DI
GWH24AGEXH-D3DNA4A/I
Indoor Unit Product Code CB385N16400
CB385N16300
CB558N09000
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ108×830 Φ108×830
Cooling Speed r/min 1500/1150/1100/1000/950/900/850 1500/1150/1100/1000/950/900/850
Heating Speed r/min / 1500/1200/1100/1050/1000/950/900
Fan Motor Power Output W 60 60
Fan Motor RLA A 0.3 0.3
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 845×25.4×342.9 845×25.4×342.9
Swing Motor Model MP24AK/MP24HF/MP24HF MP24AK/MP24HF/MP24HF
Swing Motor Power Output W 1.5/1.5/1.5 1.5/1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 52/44/42/39/38/36/34
Cooling: 52/44/42/39/38/36/34
Heating: 52/44/42/39/38/36/34
Sound Power Level dB (A) 62/54/52/49/48/46/44
Cooling: 62/54/52/49/48/46/44
Heating: 62/54/52/49/48/46/44
Dimension (WXHXD) inch 42 21/64 × 13 7/64 × 9 11/16 42 21/64 × 13 7/64 × 9 11/16
Dimension of Carton Box (LXWXH) inch 44 13/32 × 15 63/64 × 12 23/32 44 13/32 × 15 63/64 × 12 23/32
Dimension of Package (LXWXH) inch 44 39/64 × 16 19/64 × 13 7/64 44 39/64 × 16 19/64 × 13 7/64
Net Weight Ib 35.3 35.3
Gross Weight Ib 41.9 41.9
2. Specications

Tosot TW09HXP2A1A Specifications

General

Brand	Tosot
Model	TW09HXP2A1A
Category	Air Conditioner
Language	English
