Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWC24AGEXH-D3DNA1A/O
TW24HXP2A1DO
Outdoor Unit Product Code CB385W16400 CB385W16300
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO., LTD
ZHUHAI LANDA
COMPRESSOR CO., LTD
Compressor Model QXFS-M180zX170 QXFS-M180zX170
Compressor Oil / /
Compressor Type Rotary Rotary
Compressor LRA. A 24 24
Compressor RLA A 11 11
Compressor Power Input W 1350 1350
Compressor Overload Protector HPC 115/95U1 KSD115°C HPC 115/95U1 KSD115°C
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range ºF 61~86 61~86
Cooling Operation Ambient Temperature Range ºF 0~122 -20~122
Heating Operation Ambient Temperature Range ºF / -22~86
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7 Φ7
Condenser Rows-n Gap mm 2-1.4 2-1.4
Condenser Coil Length (LXDXW) mm 955×38.1×704 955×38.1×704
Fan Motor Speed rpm 850 850
Fan Motor Power Output W 90 90
Fan Motor RLA A 0.6 0.6
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 2648 2648
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ570 Φ570
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level dB (A) 62 62
Sound Power Level dB (A) 72 72
Dimension (WXHXD) inch 39 3/8 × 29 3/8 × 16 13/16 39 3/8 × 29 3/8 × 16 13/16
Dimension of Carton Box (LXWXH) inch 42 13/32 × 18 57/64 × 30 29/32
42 13/32 × 18 57/64 × 30 29/32
Dimension of Package (LXWXH) inch 42 33/64 × 19 1/64 × 31 57/64 42 33/64 × 19 1/64 × 31 57/64
Net Weight Ib 125.7 125.7
Gross Weight Ib 136.7 136.7
Refrigerant R410A R410A
Refrigerant Charge oz 60 60
Connection
Pipe
Connection Pipe Length ft 24.6 24.6
Connection Pipe Gas Additional Charge oz/ft 0.2 0.5
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 5/8 5/8
Max Distance Height ft 82 82
Max Distance Length ft 131.2 131.2
Note: The connection pipe applies metric diameter.
