1
2
4
3
Mode Indicators
Selects the operation mode of the equipment.
HEAT - indicates the heat mode.
COOL - indicates the air conditioning mode.
AUTO - indicates the system will automatically
changeover between heat and cool modes
as the temperature varies.
OFF - indicates the entire system is turned off.
PROGRAM ON - indicates the stored program
is enabled to run. Page 9.
Clock with Day of the Week
Indicates the current time and day. This clock is
also used to program the time periods. Page 5.
Room Temperature Display
Indicates the current room temperature.
Desired Set Temperature
Indicates desired room temperature(s). Page 7.
Display
Page 3
1
1
1
2
3
11
4
4
7
10
8
6
9
1
12
12
5
88
88
DRY
%
OFFON
AUTO
Program
Service
Filter
Locked
Outside
Humidity
Setup
On
o
o
Am
Pm
18:88
88
Day
Night
Evening
Morning
:
SuMTuWThFSa
HEAT
COOL
To Next Page
