INSTALLATION INSTRUCTIONS
Sample Wiring Diagrams
Gas or Electric Heat
Page 15
FAN
POWER
G
R
W
W
Y
B
O
G
R
3 Wire, 1 Stage Heat
Residential Gas or Electric Heat units
with a separately controlled fan.
GAS OR
ELECTRIC HEAT
3 Conductor 18 to 22 gauge
unshielded cable from the
thermostat to the equipment.
