INSTALLATION INSTRUCTIONS
Sample Wiring Diagrams
Gas or Electric Heat
Page 17
FAN
POWER
G
RY
W
Y
B
O
G
R
3 Wire, 1 Stage Cooling
Residential Electric Cool units
COOLING
3 Conductor 18 to 22 gauge
unshielded cable from the
thermostat to the equipment.
