tousek / E_PULL-T5-T8-T10-T15_04 / 06. 08. 2019 - 19 -
Attention
With force adjustment the valid safety regulations and standards have to be strictly followed !
max. force 70% (factory setting) Motor
25–100% adjustable [increment 5]: determines the max. possible motor force.
ARS response time 0,50s (factory setting) Motor
0,15–0,95s adjustable [increment 0,05]: determines, in which time the AR-System responds. The lower the value,
the more sensitive the sensor will react.
speed 100% (factory setting) Motor
65–100% adjustable [increment 5]: determines the speed of motor.
soft stop way 0,5m (factory setting) Motor
0–2m adjustable [increment 0,1]: determines the distance of soft run.
soft speed 50% (factory setting) Motor
30 (PULL T15: 50)–60% adjustable [increment 5]: determines the speed during soft run.
limit position OPEN -5 (factory setting) Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected OPEN limit position of gate (e.g. for
safety sensing barriers). With adjustment 0 the motor runs to the previously learned open position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
By deleting the limit positions in the menu „DIAGNOSIS / delete positions“ the adjusted value for „limit position OPEN“ will
be deleted as well. The factory setting -5 will be saved.
limit position CLOSE -5 (factory setting) Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected CLOSE limit position of gate (e.g.
for safety sensing barriers). With adjustment 0 the motor runs to the previously learned close position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
By deleting the limit positions in the menu „DIAGNOSIS / delete positions“ the adjusted value for „limit position OPEN“ will
be deleted as well. The factory setting -5 will be saved.
Motor Connections and adjustments
