Characteristics PULL T5, -T8, -T10, -T15
• Programmable control panel accessible from exterior with
illuminated display in english
• Direct connection of 8,2 kOhm contact barriers (safety
sensing edges (2-channels)
• Three operating modes (impulse, automatic and dead
man)
• Adjustable partial opening
• Built in control board in separate housing
• Safety system ARS (automatic reversal system)
• Self locking worm gear
• Emergency release, lockable with prole half cylinder (3 keys
included) - changeable, thus incorporation into an existing
house key system is possible.
• Self learning end positions (limits)
• Drive unit (gearbox unit) made of steel and runs in an oil bath
• Permanently selearning force
• Adjustable soft stop (no loss of force even with reduced
revolution speed)
• worm gear and worm wheel made of tempered steel
•
1. General Sliding gate operator PULL T5, -T8, -T10, -T15
Characteristics PULL T5
• Up to 500kg and
20 cycles/day
Characteristics PULL T8
• up to 800kg and
40% duty cycle
Characteristics PULL T10
• up to 1000kg and
40–60% duty cycle
Characteristics PULL T15
• up to 1500kg and
60% duty cycle
Technical data
Sliding gate operator
PULL-
T5 T8 T10 T15 T5 T8 T10 T15
Control board integrated Max. drive 30m
Power supply 230V a.c., 50Hz
duty cycle in
S3 mode
20
cycles/day
40% 40–60%
max. current consumption
(excl. equipment)
1,6A 1,9A 2,2A
Ambient tempera-
ture
-20°C +40°C
Gear wheel Z20M4 Z16M4 Protection class IP44
Max. gate weight 500kg 800kg 1000kg 1500kg Torque sensor
Speed 11m/min 9m/min
Article no. 11110370 11110380 11110390 11110570
Torque 20Nm 25Nm 30Nm
Optional equipment
pluggable receiver • additional module für courtyard/control lamp • additional module for gate status • bracket
incl. top hat rail • radio transmission system TX 310 • inductive system TX 400i
Motor selection by using a spring scale T5 T8 T10 T15 T24 T24speed
Attach the spring scale to the gate at approx. the height of the rack. Then pull
horizontally and without rocking at motor speed. Compare the max. detected
tractive force with the guide values listed on the right.
up to
20kg
up to
30kg
up to
40kg
up to
60kg
up to
25kg
up to
20kg
General
During the development of the new operator generation Tousek PULL T5, -T8, -T10, -T15 special attention has been paid to a quick and sim-
ple installation and a troublefree operation, together with the proven quality and reliability. Accordingly, many clever details have been built into
the operator - from the automatic learning of gate end positions, to the control board with removable clamps an integrated safety sensing edge
analysis, to an easy programmable text display - which make it particularly user-friendly. The drive unit itself consists of an electric motor and
a worm gearing, accommodated in a robust aluminium housing, and - together with the integrated microprocessor control unit and the safety
reverse system ARS - forms a compact device with small overall dimensions. The safety reverse system ARS senses obstacles during open-
ing and closing of the gate and permits a continuous adjustment of the drive force. Following the Tousek tradition, all operator components have
been built in a particularly robust and resistant way to guarantee the safe and reliable operation even in the most adverse weather conditions.
Additional improvements are for example: control board with display is accesible from outside, the separate control board housing, which double protects
this sensible part, or an oil bath which ensures that the motor/gearing components can move in an optimal way in all temperatures with perfect lubrica-
tion and cooling e󰀨ect. The installation of the PULL T5, -T8, -T10, -T15 is possible for new or already exsting sliding gates in a simple and fast way.
Functions
The integrated control board has three operation modes : impulse mode (with button/switch function open and close), automatic mode
(automatic closing) and dead-man mode (the gate moves as long as the button/switch is pressed)
Not only the possibility of connecting a button/switch OPEN / CLOSE / STOP, photocells and a safety device, but also a pedestrian entry
button/switch which enables the partial opening of the gate. The system has 230V output terminals, for connecting a signal lamp. Further it´s
equipped with slots for a pluggable radio receiver and an additional module (for courtyard lamp or for evaluating the gate state).
