tousek PULL T5 - 8 Dimensioned Drawing

- 30 - tousek / E_PULL-T5-T8-T10-T15_04 / 06. 08. 2019
We reserve the right to change dimensions and
technical specifications without prior notice.
9. Dimensioned drawing Sliding gate operator PULL T5, -T8, -T10, -T15
• Dimensions in mm
(1) lockable emergency release (euro standard cylinder)
(2) gear wheel
(3) cable entrance
(4) ground plate
(4a) slotted holes (4x) for mounting on foundation
(5) display for programming
PULL -T5 -T8 -T10 -T15
1)
gear wheel Z20M4, r44 Z16M4, r36
2)
gear wheel center 63 67
3)
gear wheel top 107 99 103
View A:
133
gear wheel
1)
gear wheel
center
2)
gear whell
top
3)
272
48,5
13,5
58,5
4a
75
3
50
25
4
309
119,5
3
3
272
48,5
40
85
52
13,5
4
58,5
4a
309
119,5
5
View B:
306,5 310,5 (PULL T15)
316
1
2
A B
206,5
22
1263,4
Fixing of the gear wheel:
- PULL T5, T8, T10: Seeger ring
- PULL T15: with screw
PULL T5, -T8, -T10: depth of ground plate = 8mm PULL T15: depth of ground plate = 12mm
