Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 12
02-02
12. Fit the in-dash changer-unit using
screws
+
.
: Screw (2x)
: Tapping screw (2x)
104
103
104
103
6
Fig. 12
13.
a) Remove the distortion spring .
b) Remove the cover from the lower
cluster panel .
3
10
9
Fig. 13
14. Attach protection tape to the lower
cluster panel as shown in order not
to damage the surface of the lower
cluster panel .
3
3
11
Fig. 14
104
103
9
10
3
11
3
