Toyota Corolla E12-A - Cluster Panel Marking Details

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 14
05-04
20. Mark the lower side of the reverse side
of the cluster panel using a ruler.
3
Fig. 20
18. Mark the right side of the cluster panel
using template ‘RH’ .
9
3
Fig. 18
19. Mark the left side of the cluster panel
using the template ‘LH’ .
10
3
Fig. 19
Marking
Marking
Marking
Ruler
5mm
55mm
55mm
55mm
25mm
5mm
25mm
185mm
185mm
9
10
10
3
3
3
