Toyota Corolla E12-A - Changer Unit Connection and Reassembly

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 9
05-04
7. Route and attach the changer wire
using tape (1x) as shown.
1
2
Fig. 7
When installing the in-dash 6CD
changer check that the changer wire
does not overlap the rear of the 6CD
changer.
CAUTION
2
1
8.
a) Connect the changer wire to the com-
bo using the conversion harness .
b) Refit the combo and centre cluster
.
: Clip (4x)
: Screw (4x)
101
5
6
34
6
2
Fig. 8
A conversion harness (P/N 08695-
00370) is needed for connection to the
audio unit.
34
NOTE
5
2
101
Reinforcement pipe
6
34
