TP-Link AC1350 User Manual

4
Chapter 1
Get to Know About Your Router
LED Explanation
Name Status Indication
(5GHz Wireless)
On The 5GHz wireless band is enabled.
Off The 5GHz wireless band is disabled.
(Internet)
Green On Internet service is available.
Orange On
The router’s Internet port is connected, but the internet service
is not available.
Off The router’s Internet port is unplugged.
(Ethernet)
On
At least one powered-on device is connected to the router’s LAN
port.
Off No powered-on device is connected to the router’s LAN port.
(USB)
On The inserted USB device is ready to use.
Flashing A USB device is being identified.
Off No device is plugged into the USB port.
(WPS)
On/Off
This light remains on for 5 minutes when a WPS connection is
established, then turns off.
Flashing WPS connection is in progress. This may take up to 2 minutes.
1. 2. 2. The Back Panel
The following parts (view from left to right) are located on the back panel.
Item Description
WPS Button Press this button to enable the WPS function..

TP-Link AC1350 Specifications

General

Frequency Band	2.4 GHz and 5 GHz
Antenna	3x External Antennas
Wireless Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Wireless Standard	IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Wi-Fi Speed	867 Mbps at 5 GHz, 450 Mbps at 2.4 GHz
USB Port	1 x USB 2.0
Security Features	Access Control
Dimensions	243 x 160.6 x 32.5 mm
