Archer C5
AC1200 Wireless Dual Band Gigabit Router
Figure 2-1 Hardware Installation
Figure 2-2 Wall-mount Installation

Note:
The diameter of the screw ranges from 3.5 mm to 8 mm, and the distance between two screws is
122 mm. The screw that projects from the wall needs around 4.5 mm base, and the length of the
screw needs to be at least 20 mm to withstand the weight of the product.
- 8 -
