TP-Link Archer T2UH - Connecting via WPS; PBC (Push Button Configuration) Method

Archer T2UH
AC600 High Gain Wireless Dual Band USB Adapter
3.2 To connect using WPS
WPS (Wi-Fi Protected Setup) function allows you to add a new wireless device to an existing
network quickly.
If your wireless Router supports WPS or QSS (Quick Security Setup), you can establish a
wireless connection between wireless card and Router using either Push Button Configuration
(PBC) method or PIN method. Three WPS connection methods are listed in the following parts.
3.2.1 PBC (Push Button Configuration) method
1. Press the WPS or QSS button on the Router. Here we use Router Archer C7 as an
example. Press the WPS/Reset button for 2~3 seconds.
2. Press the WPS button on the adapter. There are two ways:
 Method One：
Press and hold the WPS button on the adapter directly for 3 seconds until Figure 3-9 appears.
Figure 3-9
13
