TP-Link CPE Series User Manual

Quick Start Guide (CPE and WBS) Set Up the Wireless Network
Configuration Guide
10
Note:
There may be two or more networks with the same SSID in the AP list. Click Lock to AP to select the
SSID and AP simultaneously, which can make the device connect to the specific AP next time.
Figure 3-8 Selecting an Upstream Wireless Network
5) In the Wireless Client Settings section, specify the wireless parameters to connect to
the specified wireless network. Click
Next .
Note:
Make sure that Security and PSK Password are the same as the upstream wireless network’s. Other
parameters set in this page and those of the upstream wireless network should be compatible with
each other. For details, refer to
Configure the Wireless Parameters
.

TP-Link CPE Series Specifications

General

Model	CPE Series
Wireless Standards	IEEE 802.11a/n
Frequency	5 GHz
Antenna	Directional
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Operating Modes	Access Point, Client, Repeater, Bridge
Power Supply	Passive PoE (Power over Ethernet)
Operating Temperature	-30°C to 70°C
Storage Temperature	-40°C~70°C (-40℉~158℉)
Humidity	10%~90% non-condensing
Enclosure	Weatherproof design
Chipset	Atheros
RAM	Varies by Model
Flash Memory	Varies by Model
Ethernet Ports	1
