TP-Link CPE Series User Manual

Quick Start Guide (CPE and WBS) Log In to the Device
Configuration Guide
3
2
Log In to the Device
Before configuring the device, you need to access the PharOS configuration interface.
Follow the steps below:
1) Connect your PC to the device.
2) Set the IP address of your PC as static IP address on 192.168.0.X subnet (X ranges from
2 to 253, e.g.192.168.0.10)
Figure 2-1 Specifying the IP Address
3) Launch a web browser on and enter the management IP address of the device
(192.168.0.254 by default) in the address bar to load the login page of the PharOS
configuration interface.
Figure 2-2 Entering the Management IP Address
4) Use admin for both of User Name and Password . Select the appropriate language from
the Language drop-down list. Read and agree the terms of use, then click
Login .

TP-Link CPE Series Specifications

General

Model	CPE Series
Wireless Standards	IEEE 802.11a/n
Frequency	5 GHz
Antenna	Directional
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Operating Modes	Access Point, Client, Repeater, Bridge
Power Supply	Passive PoE (Power over Ethernet)
Operating Temperature	-30°C to 70°C
Storage Temperature	-40°C~70°C (-40℉~158℉)
Humidity	10%~90% non-condensing
Enclosure	Weatherproof design
Chipset	Atheros
RAM	Varies by Model
Flash Memory	Varies by Model
Ethernet Ports	1
