TP-Link Jetstream Series Installation Guide

JetStream Smart Switch
06 Introduction
LED Indication
100Base-FX
1000Base-X
SFP1, SFP2
Green On: A 1000 Mbps device is linked to the corresponding port, but no activity.
Green Flashing: A 1000 Mbps device is linked to the corresponding port and data is
being transmitted or received.
Yellow On: A 10/100 Mbps device is linked to the corresponding port, but no activity.
Yellow Flashing: A 10/100 Mbps device is linked to the corresponding port and is
transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note:
1000Base-X for port 25–28 of TL-SG2428P. 100Base-FX/1000Base-X for port
49–52 of T1600G-52PS (TL-SG2452P)
. SFP1/SFP2 for TL-SG2210MP.
100Base-FX and 1000Base-X ports don't support 10 Mbps device.
LED Mode Switch Button
Press this button to switch the LED status indication between Speed and PoE.
Reset
With the switch powered on, press Reset button for 5 seconds to reset the switch to its factory default
settings.
Unit ID LED
Designed to display the stack Unit ID of the switch. For the switch that does not join any stack system, it
displays its default Unit ID. To modify the default unit number, please log on to the GUI of the switch and
go to Stack→Stack Management→Stack Cong page and congure the New Unit ID. The new Unit ID
will take eect after you reboot the switch.
10/100 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps or 100 Mbps.
10/100/1000 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps, 100 Mbps or 1000 Mbps.
SFP Port
Designed to install the SFP module. For products except T1700X-16TS, the switch features some slots
that are shared with the associated RJ45 ports. The associated two ports are referred as a "Combo"
port, which means they cannot be used simultaneously, otherwise only SFP port works.
SFP+ Port
Designed to install the SFP module. For T1700G-28TQ and T1700X-16TS, the switch supports 1 G or
10 G SFP module connection.
Port Feature
Model
100M/1000 M/10Gbps
RJ45 Port
10/100/1000 Mbps
RJ45 Port
10/100 Mbps RJ45
Port
SFP Port SFP+ Port
T1500-28TC / 4 24 2 /
T1500-28PCT / 4 24 2 /
T1600G -18TS / 16 / 2 /
T1600G-28TS / 24 / 4 /
T1600G-52TS / 48 / 4 /
T1600G-52PS / 48 / 4 /
