TP-Link JetStream T1500-28TC User Manual

Monitoring Traffic Traffic Monitor
User Guide 731
1
Traffic Monitor
With Traffic Monitor function, you can monitor each port’s traffic information, including the
traffic summary and traffic statistics in detail.
1.1 Using the GUI
Choose the menu MAINTENANCE > Traffic Monitor to load the following page.
Figure 1-1 Traffic Summary
Follow these steps to view the traffic summary of each port:
1) To get the real-time traffic summary, enable Auto Refresh, or click Refresh.
Auto Refresh: With this option enabled, the switch will automatically refresh the traffic summary.
Refresh Interval: Specify the time interval for the switch to refresh the traffic summary.
2) In the Traffic Summary section, click UNIT1 to show the information of the physical
ports, and click LAGS to show the information of the LAGs.
Packets Rx: Displays the number of packets received on the port. Error packets are not
counted.
Downloaded from ManualsNet.com search engine

TP-Link JetStream T1500-28TC Specifications

General

Switch Type	Managed
Switching Capacity	56 Gbps
Power Supply	100-240VAC, 50/60Hz
MAC Address Table	8K
Jumbo Frame	Up to 9216 bytes
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Dimensions	440 x 180 x 44 mm
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s
Mounting	Rackmount
Packet Forwarding Rate	41.7Mpps
Quality of Service	802.1p, DSCP
L2 Features	Port Mirroring, Loopback Detection
VLAN	802.1Q VLAN
Access Control List	L2/L3/L4 ACL
Security	IP-MAC-Port Binding, DHCP Snooping, ARP Inspection
Management	Web, CLI, SNMP
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
