TP-Link JetStream T1500-28TC User Manual

Configuration Example
User Guide 803
Figure 6-12 Configuring the Alarm Entries
5) Click to save settings.
6.4 Using the CLI
■ Configuring Storm Control on ports
Configure the Storm Control on the required ports of Switch A. For detailed
configuration, refer to Configuring QoS .
■ Configuring SNMP
1) Enable SNMP and specify the remote engine ID.
Switch_A#configure
Switch_A(config)#snmp-server
Switch_A(config)#snmp-server engineID remote 123456789a
2) Create a view with the name View; set the MIB Object ID as 1 (which represents all
functions), and the view type as Include.
Switch_A(config)#snmp-server view View 1 include
3) Create a group of SNMPv3 with the name of nms-monitor. Enable Auth Mode and
Privacy Mode, and set both the Read and Notify views as View.
Switch_A(config)#snmp-server group nms-monitor smode v3 slev authPriv read View
notify View
4) Create an SNMP user named admin. Set the user as a remote user and configure the
security model and security level based on the group. Set the Auth Mode as SHA
algorithm, password as 1234, the Privacy Mode as DES, and password as 1234.
Switch_A(config)#snmp-server user admin remote nms-monitor smode v3 slev authPriv
cmode SHA cpwd 1234 emode DES epwd 1234
5) To configure Notification, specify the IP address of the NMS host and UDP port. Set the
User, Security Model and Security Level according to configurations of the SNMP User.
Downloaded from ManualsNet.com search engine

TP-Link JetStream T1500-28TC Specifications

General

Switch Type	Managed
Switching Capacity	56 Gbps
Power Supply	100-240VAC, 50/60Hz
MAC Address Table	8K
Jumbo Frame	Up to 9216 bytes
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Dimensions	440 x 180 x 44 mm
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s
Mounting	Rackmount
Packet Forwarding Rate	41.7Mpps
Quality of Service	802.1p, DSCP
L2 Features	Port Mirroring, Loopback Detection
VLAN	802.1Q VLAN
Access Control List	L2/L3/L4 ACL
Security	IP-MAC-Port Binding, DHCP Snooping, ARP Inspection
Management	Web, CLI, SNMP
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
