TP-Link JetStream T1500-28TC User Manual

RMON Configurations
User Guide 787
3) Enter the owner name, and set the status of the entry. Click Apply.
Owner Enter the owner name of the entry with 1 to 16 characters. By default, it is
monitor.
Status Enable or disable the entry. By default, it is disabled.
Enable: The entry is enabled.
Disable: The entry is disabled.
Note:
To change the parameters of a History entry, enable the entry at the same time; otherwise, the change
cannot take effect.
5.1.3 Configuring Event Group
Choose the menu MAINTENANCE > SNMP > RMON > Event to load the following page.
Figure 5-3 Configuring the Event Entry
Follow these steps to configure the Event group:
1) Choose an Event entry, and specify an SNMP User for the entry.
Index Displays the index of Event entries. The switch supports up to 12 Event entries.
User Choose an SNMP user name or community name for the entry. Only the specified
user can access the log messages or receive the notification messages related to
the event.
2) Set the description and action to be taken when the event is triggered.
Description Enter an brief description of this event to make it easier to be identified.
Downloaded from ManualsNet.com search engine

TP-Link JetStream T1500-28TC Specifications

General

Switch Type	Managed
Switching Capacity	56 Gbps
Power Supply	100-240VAC, 50/60Hz
MAC Address Table	8K
Jumbo Frame	Up to 9216 bytes
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Dimensions	440 x 180 x 44 mm
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s
Mounting	Rackmount
Packet Forwarding Rate	41.7Mpps
Quality of Service	802.1p, DSCP
L2 Features	Port Mirroring, Loopback Detection
VLAN	802.1Q VLAN
Access Control List	L2/L3/L4 ACL
Security	IP-MAC-Port Binding, DHCP Snooping, ARP Inspection
Management	Web, CLI, SNMP
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
