Figure 9-11 Storm Control
The following entries are displayed on this screen:
Storm Control Config
Port Select:
Click the Select button to quick-select the corresponding port
based on the port number you entered.
Select:
Select the desired port for Storm Control configuration. It is
multi-optional.
Port:
Displays the port number of the Switch.
Broadcast: Enable/Disable broadcast control feature for the port.
Multicast: Enable/Disable multicast control feature for the port.
UL-Frame: Enable/Disable UL-Frame control feature for the port.
Rate (bps): Select the bandwidth for receiving the specified packet on the port.
The packet traffic exceeding the bandwidth will be discarded.
LAG: Displays the LAG number which the port belongs to.
Note:
If you enable storm control feature for the ingress rate limit-enabled port, ingress rate limit feature
will be disabled for this port.
9.3 Voice VLAN
Voice VLANs are configured specially for voice data stream. By configuring Voice VLANs and
adding the ports with voice devices attached to voice VLANs, you can perform QoS-related
