TP-Link M5250 User Manual

M5250
3G Mobile Wi-Fi User Guide
-2-
Chapter 1. Introduction
1.1 Product Overview
TP-LINK’s M5250 is at the forefront of wireless 3G sharing. Equipped with a built-in 3G modem,
you can instantly establish your own Wi-Fi hotspot simply by inserting a 3G SIM card at the
interior of the device. With up to 21.6Mbps download and 5.76Mbps upload speeds, M5250 is
able to provide 3G wireless sharing to up to 10 users simultaneously. Its pocket-sized design
and powerful 2000mAh internal battery make it an ideal travel companion, allowing users to
work or play for hours on end.
1.2 Main Features
 Equipped with a built-in 3G modem - No other bulky devices required
 HSPA+ supported with up to 21.6Mbps download and 5.76Mbps upload speeds
 Supports up to 10 users simultaneously
 2000mAh internal battery for extended hours of outdoor use
 Portable and cobblestone design ideal for travel use
 Micro USB port for versatile recharging
 LED display provides an intuitive view of the device’s working status
 Equipped with a micro SD card slot for up to 32GB of optional storage
1.3 Physical Description
Figure 1-1 the Exterior
Figure 1-2 the Interior
Power Button
LED
Scree n
Micro USB Port
SIM Card Slot
Micro SD Memory
Card Slot
RESET Button (hole)

TP-Link M5250 Specifications

General

DHCP client	Yes
Ethernet LAN	No
Ethernet LAN (RJ-45) ports	0
Data network	EDGE, GPRS, GSM, HSPA, HSPA+, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Device type	Cellular wireless network equipment
Certification	CE, FCC, RoHS
Product color	Black
LED indicators	Power, Status, WLAN
Web-based management	-
Security algorithms	SSID, WPA-PSK, WPA2-PSK
Market positioning	Portable

Weight and Dimensions

Depth	56.7 mm
Width	94 mm
Height	19.8 mm
Weight	92.5 g
