11
Chapter 2
Set Up Internet Connection
2 ) Press (power button) to enter the Device Info page.
Device Info
SSID: TP-Link_XXXX
Password: XXXXXXXX
Login Address:
http://tplinkmi.net
Device Info
3 ) On your device, select the SSID and enter the Password which you find on
the screen.
Method Two: Via WPS (Wi-Fi Protected Setup)
If you have a WPS-supported device (such as Android phones or tablets), you
can connect to the Mobile Wi-Fi more easily using WPS button or PIN.
Note:
To use the WPS function, please make sure the SSID Broadcast function and wireless function are
enabled.
Via the WPS button
1 ) Press
(menu button) to enter the menu page and switch to the WPS
menu.
4G
R
2
1
100%
WPS
2 ) Press (power button) to enter the WPS page.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link m7310 and is the answer not in the manual?

TP-Link m7310 Specifications

General IconGeneral
Wi-FiYes
WLAN data transfer rates supported150 Mbit/s
Device typeCellular wireless network equipment
CertificationCE, RoHS
Product colorBlack, Grey
Compatible memory cardsMicroSD (TransFlash)
Data networkEDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
GSM bands supported850, 900, 1800, 1900 MHz
UMTS bands supported900, 2100 MHz
Number of simultaneous SIM cards1
Battery voltage5 V
Battery capacity2000 mAh
Display diagonal1.44 \
Security algorithmsWPA-PSK, WPA2-PSK
Operating frequency2.4, 5 MHz
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Market positioningPortable
Weight and Dimensions IconWeight and Dimensions
Depth60.5 mm
Width98.5 mm
Height16 mm
