TP-Link Omada EAP230-Wall User Manual

54
Connection
Threshold/Difference
Threshold
Connection Threshold defines the maximum number of clients
connected to the 5GHz band. The value of Connection Threshold
is from 2 to 40, and the default is 20.
Difference Threshold defines the maximum difference between
the number of clients on the 5GHz band and 2.4GHz band. The
value of Difference Threshold is from 1 to 8, and the default is 4.
When the following two conditions are both met, the EAP prefer to
refuse the connection request on 5GHz band and no longer steer
other clients to the 5GHz band:
1.The number of clients on the 5GHz band reaches the Connection
Threshold value.
2.The difference between the number of clients on the 2.4GHz
band and 5GHz band reaches the Difference Threshold value.
Max Failures If a client repeatedly attempts to associate with the EAP on the
5GHz band and the number of rejections reaches the value of Max
Failures, the EAP will accept the request.
The value is from 0 to 100, and the default is 10.
3. Click Save.

TP-Link Omada EAP230-Wall Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Virtual LAN features	Port-based VLAN, VLAN mapping
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	20 - 23 dBm
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Number of products included	2 pc(s)
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Placement	Wall
Product color	White
LED indicators	Operation
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	3.6 dBi
Power consumption (max)	25.5 W
Power consumption (typical)	9 W
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1
Harmonized System (HS) code	85176990
Package depth	130 mm
Package width	118 mm
Package height	47 mm
Package weight	210 g
Sustainability certificates	CE, RoHS

Weight and Dimensions

Width	86.8 mm
Height	30.2 mm
