Name Status Indication
(Internet)
Off Internet service is not available.
On Internet service is available.
Flashing The modem is initializing.
(LAN)
On The LAN port is connected.
Off The LAN port is not connected.
Flashing The LAN port is sending or receiving data.
2.2 Back Panel
Reset: With the modem powered on, use a pin to press and hold the Reset button until all
LEDs turn on momentarily. And the modem will be reset to its factory default settings.
LAN: Through this port, you can connect the modem to your PC or the other Ethernet
network device.
Cable: Through this port, you can connect the modem to coaxial cable.
Power: The power plug where you will connect the power adapter.
2.3 Installation Environment
The product should not be located where it will be exposed to moisture or excessive heat.
Place the modem in a location where it can be connected to the various devices as well as to
a power source.
4
