TD-8816 ADSL2+ Modem Router User Guide
30
4.4 Advanced Setup
Choose “Advanced Setup”, you can see the next submenus:
Figure 4-18
Click any of them, and you will be able to configure the corresponding function.
4.4.1 Firewall
Choose “Advanced Setup→Firewall” menu, and you will see the next screen (shown in Figure
4-19).
Figure 4-19
Firewall: If you enable Firewall, the modem can automatically detect and block Denial of
Service (DoS) attacks, such as Ping of Death, SYN Flood, Port Scan and Land Attack.
SPI: If you enable SPI, all traffics initiated from WAN would be blocked, including DMZ,
Virtual Server, and ACL WAN side.
4.4.2 Routing
Choose “Advanced Setup→Routing” menu, and you will see the routing information in the next
screen (shown in Figure 4-20).
