TD-W8961ND 300Mbps Wireless N ADSL2+ Modem Router User Guide
27
Router will work as a DHCP Relay. A DHCP relay is a computer that forwards DHCP data
between computers that request IP addresses and the DHCP server that assigns the
addresses. Each of the device's interfaces can be configured as a DHCP relay. If it is enabled,
the DHCP requests from local PCs will forward to the DHCP server runs on WAN side. To
have this function working properly, please run on router mode only, disable the DHCP server
on the LAN port, and make sure the routing table has the correct routing entry.
Figure 4-13
• DHCP Server IP for Relay Agent: Enter the DHCP server IP Address runs on WAN
side.
)
Note:
If you select Disabled, the DHCP function will not take effect.
4.3.3 Wireless
Choose “Interface Setup→Wireless” menu, and you will see the Wireless screen (shown in
Figure 4-14 ). Please configure the parameters for wireless according to the descriptions below.
To Next Page
