TD-W8101G 54M Wireless ADSL2+ Router User Guide
27
4.4 Advanced Setup
Choose “Advanced Setup”, you can see the next submenus:
Figure 4-17
Click any of them, and you will be able to configure the corresponding function.
4.4.1 Firewall
Choose “Advanced Setup→Firewall” menu, and you will see the next screen (shown in Figure
4-18).
Figure 4-18
¾ Firewall: Select this option can automatically detect and block Denial of Service (DoS)
attacks, such as Ping of Death, SYN Flood, Port Scan and Land Attack.
¾ SPI: If you enable SPI, all traffics initiated from WAN would be blocked, including DMZ, Virtual
Server, and ACL WAN side.
4.4.2 Routing
Choose “Advanced Setup→Routing” menu, and you will see the routing information in the next
screen (shown in Figure 4-19).
Figure 4-19
Click ADD ROUTE button to add a new route in the next screen (shown in Figure 4-20).
