JetStream L2/L2+ Managed Switch
02Introduction
The front panel of TL-SG3210 is shown as the following figure.
Figure 1-3 Front Panel of TL-SG3210
1000Mbps
10/100Mbps
Activity
10/100/1000M
1000Mbps
100Mbps
Activity
SFP
2
1
4
3
6
5
8
7
10
9
PWR
SYS
10/100/1000M
TL-SG3210
L2+ Managed Switch
SFP
Console Port
(RJ45/USB)
LED
1G RJ45 Port
SFP Slot
The front panel of TL-SG3210XHP-M2 is shown as the following figure.
Figure 1-4 Front Panel of TL-SG3210XHP-M2
LED Console Port
(RJ45/USB)
2.5G
RJ45 Port
SFP+ Slot
The front panel of TL-SG3428 V2.0 is shown as the following figure.
Figure 1-5 Front Panel of TL-SG3428 V2.0
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP Slot
24-Port Gigabit L2+ Managed Switch
with 4 SFP Slots
The front panel of TL-SG3428MP V2.0 is shown as the following figure.
Figure 1-6 Front Panel of TL-SG3428MP V2.0
LED Console Port
(RJ45/USB)
1G
RJ45 Port
SFP Slot
