03 Introduction
The front panel of TL-SG3428X is shown as the following figure.
Figure 1-7 Front Panel of TL-SG3428X
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP+ Slot
24-Port Gigabit L2+ Managed Switch
with 4 10GE SFP+ Slots
The front panel of TL-SG3428XMP is shown as the following figure.
Figure 1-8 Front Panel of TL-SG3428XMP
LED Console Port
(RJ45/USB)
1G
RJ45 Port
SFP+ Slot
The front panel of TL-SG3452 is shown as the following figure.
Figure 1-9 Front Panel of TL-SG3452
F
LED
1G RJ45 Port
SFP Slot
Console Port
(USB/RJ45)
The front panel of TL-SG3452P is shown as the following figure.
Figure 1-10 Front Panel of TL-SG3452P
F
LED
1G RJ45 Port
SFP Slot
Console Port
(RJ45/USB)
Speed
PWR
SYS
PoE Max
FAN
PoE
Console(USB)Console(RJ45)
TL-SG3452P
Managed PoE+ Switch
PoE
Delivering Power
Over Budget
Fault
Speed
activity1000Mbps
10/100Mbps
