4
Chapter 1
Get to Know About Your Router
LED Status Indication
(WPS)
On
The LED stays on for 5 minutes when WPS connection is established,
and then goes off.
Blinking WPS connection is in progress.
Off No WPS connection is established.
Port and Button Description
Item Description
Mode Switch This button is used to switch the operation mode of the router.
WAN/LAN Port
This port functions as a WAN port in Router mode and as a LAN port in Hotspot, Access
Point, Range Extender and Client mode.
Power This port is used to connect the power adapter.
Reset (Hole) Use a pin to press and hold this button for 5 seconds to reset the router.
3G/4G USB This port is used to plug a 3G/4G USB modem or a USB disk into.
(WPS)
Press this button to establish WPS connection.
