TP-Link WBS210 - Configure Forwarding Feature

73
Go to the 1HWZRUN page. In the 0DQDJHPHQW9/$1,QWHUIDFHV section, enable the
Management VLAN function, specify
VLAN ID and click Apply . Then click Save .
Management
VLAN
Enable or disable the Management VLAN function. By default, it is disabled.
VLAN ID Specify the Management VLAN ID. The valid values are from 2 to 4094.
4.4 &RQILJXUHWKH)RUZDUGLQJ)HDWXUH
Note:
Forwarding submenu is only available in AP Router Mode and AP Client Router (WISP Client) Mode.
The IP address used on the internet is public IP address, while IP address used on local
area network is private IP address. The hosts using private IP addresses cannot access
the internet directly and vice versa.
The hosts using private IP addresses visit internet through NAT (Network Address
Translation) technology. NAT can transfer private IP addresses into public IP addresses to
realize the communication from internal hosts to external hosts.
If the hosts on the internet want to visit the hosts on local area network, the forwarding
function should be used, including DMZ, Virtual server, Port triggering and UPnP.
Go to the 1HWZRUN page. In the )RUZDUGLQJ section, configure the following parameters
and click
Apply . Then click Save .
DMZ Enable or disable the DMZ function. DMZ (Demilitarized Zone) specifically
allows one computer/device behind NAT to become “demilitarized”, so all
packets from the external network are forwarded to this computer/device.
The demilitarized host is exposed to the wide area network, which can
realize the unlimited bidirectional communication between internal hosts
and external hosts.
