TPS Blue M DC256 - Page 19

BLUE M
Blue M - - DC 146 Series Industrial Ovens, Models DC, DCW, DCI, DCC
Page 19
MODEL DCI336
MODEL DCI256 - REAR with STAND
Oven Stand
Cooling Coil Water
Supply Connection
Inert Gas Control
System & Supply
Connection - -
Cover Removed
Chamber Pressure
Relief Valve
Mach. Compartment -
Panel Removed
Light Tower
Chart Recorder
Power Supply
Junction Box
Thermocouple
Ports
Air Press.
Sense Ports
Model DCI
Differential Air
Pressure Switch
Adjustment Port
