Blue M - - DC 146 Series Industrial Ovens, Models DC, DCW, DCI, DCC
Page 28
5.9 Compressed Air Supply Connection for Pneumatic Door Lock (Optional)
A compressed air supply is required for operation of the pneumatic door lock system. The supply should be
clean and dry and rated 25 to 40 PSIG maximum. The connection is made to a port located at the rear of the
oven and is Type 1/4” FPT. Make sure the connection is secure.
COMPRESSED AIR SUPPLY CONNECTION
Pneumatic Door Lock
Solenoid SOL1241
