BLUE M
Blue M - - DC 146 Series Industrial Ovens, Models DC, DCW, DCI, DCC
Page 34
CONDITIONING PLENUM – MODEL DCC336
Discharge Air
Heaters
Air Diffuser
Blower Wheel
CONDITIONING PLENUM – MODEL DC256
Air Intake Damper
in Closed Position
Discharge Air
Access Port
Heater
Air Diffuser
Blower Wheel
Water-Cooled Coil
Exhaust Port
Diff. Air Press.
Sense Tube
Diff. Air Press.
Sense Tubes
Model DCC336
Model DC256
Inert Gas Port
Below Wheel
Thermocouple Ports
