8.4.3.45.3 Attribute 0xDE, Incremental Pulses per revolution
Inkremental Pulses per revolution specifies the number of pulses that can be
output per revolution via the incremental interface.
UDINT
Incremental Pulses per revolution
Byte 0
Byte 1
Byte 2
Byte 3
2
7
to 2
0
2
15
to 2
8
2
23
to 2
16
2
31
to 2
24
Access
Set / Get
Lower limit
4*
Upper limit
36000*
* Depending on the hardware version of the measuring system.
Connection path, Packed EPATH with 8 bit class
0x20
0x23
0x24
0x01
0x30
0xDE
Logical Type
= Class
Class #23
Logical Type
= Instance
Instance #1
Logical Type
=Attr.-ID
Attr.-ID #222
To save this attribute permanently the attribute 0x70 Accept Parameter or service
code 0x16 save must be executed.
8.4.3.45.4 Attribute 0xDF, Incremental K0-Condition+Len
Inkremental K0-Condition+Len defines the switching time and the length of the
Incremental track K0.
BYTE, Set / Get
Bit
Value (dec.)
Description
0…3
0
K0 if K1 high and K2 high
1
K0 if K1 low and K2 high
2
K0 if K1 high and K2 low
3
K0 if K1 low and K2 low
4…7
0
K0 lasts ¼ period
1
K0 lasts ½ period *
2
K0 lasts ¾ period *
3
K0 lasts one period *
4
K0 lasts two periods *
5
K0 lasts four periods *
* Depending on the hardware version of the measuring system.
