1 General information
This interface-specific user manual contains the following topics:
• Safety instructions
• Installation
• Commissioning
• Parameterization
• Error causes and remedies
Since it has a modular structure, this User Manual is supplementary to other documentations, such as
product data sheets, dimensional drawings, brochures, the Safety Manual, etc.
The User Manual may be included in the customer’s specific delivery package or it may be requested
separately.
1.1 Scope
This User Manual applies exclusively to measuring system series according to the following keys for
article numbers and types with EtherNet/IP™ interface and CIP Safety™ profile:
Article number
* 1
* 2
* 3
* 4
* 5
–
* 6
* 6
* 6
* 6
* 6
Position Designation Description
* 1
A
Explosion protection enclosure (ATEX);
C
Absolute encoder, programmable
* 2
D
Redundant dual scanning unit
* 3
V
Solid shaft
H
Hollow shaft
S
Blind shaft
* 4
582
Outer diameter
∅
58 mm, Generation 2
* 5
M
Multi-turn
S
Singleturn
* 6
–
Consecutive number
* = placeholder
Type key
See Revision List:
CD_582M +FS02: www.tr-electronic.de/f/TR-ECE-TI-D-0343
CD_582M +FS03: www.tr-electronic.de/f/TR-ECE-TI-D-0349
The products are labeled with affixed nameplates and are components of a system.
The following documentations therefore apply as well:
● See the Chapter “Other Applicable Documents” in the Safety Manual
www.tr-electronic.de/f/TR-ECE-BA-GB-0142
● Product data sheets www.tr-electronic.com/s/S022978
